The Seaward Apollo 600+ PAT Tester Pro Bundle Kit includes the Seaward Apollo 600+ PAT Tester and Seaward’s Test ‘n’ Tag Pro Bundle. Please see below for further information.
Seaward Apollo 600+ PAT Tester Description
The Seaward Apollo 600+ PAT Tester is the most sophisticated model in Seaward’s Apollo+ PAT Tester range. Like its sister products, the Apollo 400+ and Apollo 500+, this instrument includes extensive testing capabilities allowing it to check high volumes of portable appliances in accordance with the IET 5th Edition Code of Practice. However, the Apollo 600+ also includes a colour camera for capturing images of portable appliances, as well as a number of functions that make the Apollo 600+ suitable for performing health and safety checks in addition to PAT testing. These include:
- A universal risk assessment tool: record hazards, calculate risk scores, plan and document corrective actions.
- Onboard reports for fire detection and emergency lighting: particularly useful when conducting health and safety management applications.
Like its sister product, the Apollo 500+, the Seaward Apollo 600+ PAT Tester also features a risk-based retest calculator, allowing the user to determine when the inspected appliance will require re-testing according to the IET 5th Edition Code of Practice. Similarly, it includes the following testing capabilities:
- Low current earth continuity test, with Zap circuit, guaranteeing accurate measurements
- Insulation resistance
- IEC lead test
- Protective conductor current
- Touch current
- Load power/ current
- Alternative leakage current
- RCD test
- Power socket test
- Point-to-point fixed appliance testing for earth continuity and insulation resistance
These tests can be organised into up to 100 user-customised electrical and visual inspection test sequences. The Seaward Apollo 600+’s extensive memory can also accommodate up to 50 000 appliance records and 2000 images.
Information recorded by the Seaward Apollo 600+ PAT Tester can be transferred directly onto a USB drive, a capability that is unique to the Apollo 600+; alternatively, data can be sent to a PC via a USB cable or to a compatible Android device via Bluetooth.
Additionally, the Seaward Apollo 600+ PAT Tester is an updated version of the Apollo 600 and as such includes a number of improvements to its software compatibility, firmware and hardware. Please see below for further details.
Software Features
Once information is uploaded to a PC, Seaward’s PATGuard 3.4 Software with Time Manager (NOT included) can be used to organise the results into a report. This software is also suitable for creating invoices and the Time Manager function may be utilised in order to organise teams of workers.
As mentioned above, the Seaward Apollo 600+ PAT Tester includes Bluetooth communication capabilities allowing it to transfer information to compatible Android devices. In addition to this, the Seaward Apollo 600+ PAT Tester is compatible with the printer and scanner included in the Seaward Test ‘n’ Tag Pro Bundle (see below). These instruments facilitate the Seaward Apollo 600+ PAT Tester’s ability to read and print labels with 1D barcodes.
Firmware Features
- User permissions for Bluetooth
- A delete option for unwanted results
- The ‘View Data Menu’ has been redesigned to facilitate faster scrolling
- An advanced search function has been included on the ‘View Data Menu’, allowing the user to filter results according to specifications such as the PASS/ FAIL status of each test
- Print results automatically using the ‘After Test’ function
- The leakage test setup includes options for the ‘Worst’ and ‘Last’ results
- Options can be deleted from predictive drop-down menus, allowing the user to tailor them to his/her requirements
- Download information to an Android device using USB on-the-go technology
- Name downloaded files using unique identifiers
- The socket-outlet test allows the user to measure mains voltage and outlet wiring polarity
- The asset’s ID is displayed on all the test screens
- The review step allows test information to be checked prior to the addition of final comments
Hardware Features
The tester is supplied with a wiring harness, test leads with PVC insulation and resilient probes making it suitable for demanding applications.
It also includes a removable, interchangeable battery pack which keeps downtime to a minimum, particularly as the Seaward Apollo 600+ PAT Tester can also be powered using a mains supply.
In addition to these hardware updates, the Seaward Apollo 600+ PAT Tester includes a QWERTY keyboard and colour, high-definition display, features found on its predecessor the Apollo 600.
The Seaward Apollo 600+ PAT Tester is a comprehensive, sophisticated tester suitable for PAT testing and health and safety applications.
Seaward Apollo 600+ PAT Tester Key Features
- Most sophisticated model in Seawards Apollo + range
- Suitable for checking high-volumes of portable appliances in accordance with the IET 5th Edition Code of Practice
- Includes a colour camera for capturing images of portable appliances
- Images may serve as evidence of visual inspections
- Suitable for performing health and safety checks
- Includes a universal risk assessment tool
- Onboard reports for fire detection and emergency lighting
- Risk-based retest calculator
- Low current earth continuity test with Zap circuit, guaranteeing accurate measurements
- Insulation resistance
- IEC lead test
- Protective conductor current
- Touch current
- Load power/ current
- Alternative leakage current
- RCD test
- Power socket test
- Point-to-point fixed appliance testing for earth continuity and insulation resistance
- Organise tests into up to 100 user-customised test sequences
- Extensive memory (capacity for 50 000 appliance records and 2000 images)
- Transfer information directly onto a USB drive
- Send data to a PC via a USB cable
- Send results to a compatible Android device via Bluetooth
- An updated version of the Apollo 600
- Compatible with Seaward’s PATGuard 3.4 Software with Time Manager (NOT included)
- Compatible with the scanner and printer included in the Seaward Test ‘n’ Tag Pro Bundle
- Can read and print 1D barcode labels when used with the scanner and printer in the Seaward Test ‘n’ Tag Pro Bundle
- New user permissions for Bluetooth
- A delete option for unwanted results
- The ‘View Data Menu’ has been redesigned to facilitate faster scrolling
- An advanced search function has been included on the ‘View Data Menu’, allowing the user to filter results according to specifications such as the PASS/ FAIL status of each test
- Print results automatically using the ‘After Test’ function
- The leakage test setup includes options for the ‘Worst’ and ‘Last’ results
- Options can be deleted from predictive drop-down menus, allowing the user to tailor them to his/her requirements
- Download information to an Android device using USB on-the-go technology
- Name downloaded files using unique identifiers
- The socket outlet test allows the user to measure mains voltage and outlet wiring polarity
- The asset’s ID is displayed on all the test screens
- Using the review step test information may be checked prior to the addition of final comments
- Supplied with a wiring harness
- Supplied with test leads featuring strong PVC insulation
- Supplied with resilient test probes
- Removable, interchangeable battery
- Can be powered using a mains supply
- QWERTY keyboard
- Colour, high-definition display
- A comprehensive, sophisticated tester suitable for PAT testing and health and safety applications
Seaward Test ‘n’ Tag Pro Bundle Kit Description
The Seaward Test ‘n’ Tag Pro Bundle Kit facilitates the Seaward Apollo 600+ PAT Tester’s ability to read and print labels with 1D barcodes. This kit includes:
- 1x Seaward Test ‘n’ Tag Pro Printer – prints synthetic, durable asset labels detailing information such as a barcode, asset number, test date, next test date, username and test status. Like the Apollo 600+, this printer is also capable of Bluetooth connectivity.
- 1x Seaward 1D Bluetooth Barcode Scanner – a compact, lightweight scanner that allows the Apollo 600+ to read code 39, code 93 and code 128 1D barcodes. This instrument is powered by a rechargeable battery.
- 2x Pro Labels 25mm
- 2x Pro Labels 75mm
- 1x Apollo Kit Carry Case
- 1x 110V Test Adapter
What’s Included in the Seaward Apollo 600+ PAT Tester Pro Bundle Kit?
- 1x Seaward Apollo 600+ PAT Tester
- 1x Seaward Test ‘n’ Tag Pro Bundle
Seaward Apollo 600+ Technical Specifications
Earth Continuity | |
Test Current | ±200mA DC |
Display Range | 0.01 to 19.99Ω |
Pass Value | User defined |
Insulation Resistance | |
Test Voltage | 500V / 250V DC @ 1mA nominal |
Display Range | 0.01MΩ to 19.99MΩ |
Pass Value | User defined |
IEC Lead Test | |
Test Voltage | 5V AC nominal |
Test | Live/neutral checks for o/c, s/c and crossed |
Protective Conductor Current/Load | |
Test Voltage | Supply voltage, maximum load current 16A |
Display Range | 0.01mA to 19.99mA |
Pass Value | User defined |
Touch Current | |
Test Voltage | Supply voltage, maximum load current 16A |
Display Range | 0.00 to 5mA |
Pass Value | User defined |
Load Power/Current | |
Test Voltage | 230V + 10%, maximum load current 16A |
Test Duration | Programmable up to a maximum of 255s depending on load. i.e. max duration is reduced for high loads |
Display Range | 0.00kVA to 4.00kVA 0.00A to 16.00A |
Alternative Leakage Current | |
Test Voltages | >25V AC <50V AC |
Display Range | 0.00mA to 19.99mA |
Pass Value | User defined |
RCD Test | |
Test Voltage | 230V + 10%, -15% |
Test Current | 15mA/30mA rms sinusoidal |
Display Range | 0ms to 2000ms |
Test Method | Internal isolation to avoid tripping distribution board RCDs |
Power Socket Test | |
Voltage Range | 207V to 253V AC |
Indication of Voltage Potential | Line potential phase to earth Line potential phase to neutral Line potential neutral to earth |
General Specifications | |
Memory Size | 50000 records + 2000 photos |
Weight | 1.5kg |
Dimensions | 230 x 150mm x 100mm |
Power Source | Mains or rechargeable battery pack |
Seaward Apollo+ PAT Testers Comparison Chart
General Features | 600+ | 500+ | 400+ |
Battery & mains powered | • | • | • |
Colour screen & QWERTY keypad | • | • | • |
Large internal memory | up to 50,000 records and 2,000 photos | up to 10,000 records | up to 2,000 records |
Bluetooth scanner & printer compatible | • | • | • |
Password controlled user accounts | • | • | |
Set up multiple user accounts with varying levels of privileges | • | • | |
Clone facility to set up multiple testers | • | • | |
Checkbox supplied as standard | • | • | |
Test Inspection Features | 600+ | 500+ | 400+ |
Auto-increment asset ID | • | • | |
PAT Setup option to allow for custom menus | • | • | |
Enter asset description after test using the keypad or barcode scanner | • | • | • |
Comprehensive electrical safety test features | • | • | • |
Point to point measurement (Rpe & IR) | • | • | Optional accessory required |
User configurable electrical test/visual inspection sequences | 100 | 100 | 25 |
User set sites & locations | 100 | 100 | 50 |
Risk-based retest period calculator | • | • | |
User definable comments lines against test records | 4 | 4 | |
Configurable checklists for any workplace test or inspection (user tests) | • | • | |
Onboard camera | • | ||
Universal risk assessment | • | ||
Health & safety certificates | • | ||
Data Transfer | 600+ | 500+ | 400+ |
1D and 2D Scanner connectivity | • | • | Reads 1D Data Only |
Read QR code (2D) labels with 2D scanner | • | • | |
RFID reader connectivity | • | • | |
Print Pass & Fail labels with 1D barcode | • | • | • |
Print Pass & Fail labels with QR code (2D) | • | • | |
Add your company logo to labels (on large 1D labels only) | • | • | |
Select from various label formats to print | 6 | 6 | 6 |
Download to PC via USB cable | • | • | • |
Data Transfer via USB flash drive | • | ||
Filter results to be downloaded | • | • | • |
Upload previous results to the tester for a retest | • | • |
