Norbar Spanner End Fittings for 16mm Torque Handles – Ring End, Metric

These ring end, metric Norbar Spanner End Fittings are designed for use with Norbar’s 16mm Spigot-ended Torque Handles.

These ends are constructed from forged alloy steel and can be used interchangeably. The Norbar Ring-end, Metric Spanner End Fittings are torque handle calibrated to ensure that they give the correct torque at the nut/ bolt.

There are nineteen versions of the Norbar Ring-end, Metric Spanner End Fittings available; these differ in regards to their ranges and ring sizes.

Model Code Ring Sizes Range
NOR-29881 7mm 25 N.m
NOR-29882 8mm 35 N.m
NOR-29883 9mm 45 N.m
NOR-29884 10mm 52 N.m
NOR-29885 11mm 73 N.m
NOR-29886 12mm 89 N.m
NOR-29887 13mm 107 N.m
NOR-29889 15mm 150 N.m
NOR-29890 16mm 175 N.m
NOR-29891 17mm 201 N.m
NOR-29913 18mm 230 N.m
NOR-29914 19mm 261 N.m
NOR-29892 20mm 294 N.m
NOR-29893 21mm 330 N.m
NOR-29894 22mm 330 N.m
NOR-29895 23mm 330 N.m
NOR-29896 24mm 330 N.m
NOR-29915 27mm 330 N.m
Note Max torque values listed are proof torques quoted in BS 192:1982 & BS 3555:1988 (tested on hardened hexagon test stud)



Please note that the Norbar Ring-end Spanner End Fittings for 16mm Torque Handles are also available in imperial sizes. Additionally, blank end adapters are available for applications requiring a customised spanner (please call for details).

Norbar also offers open-end and flare-end spanner end fittings for 16mm spigot-ended torque handles.

The Norbar Spanner End Fitting for 16mm Torque Handles – Ring End, Metric are useful additions to Norbar’s 16mm Spigot-ended Torque Handles.

Norbar Spanner End Fitting for 16mm Torque Handles - Ring End, Metric Key Features

  • Designed for use with Norbar’s 16mm Spigot-ended Torque Handles
  • Constructed from forged alloy steel
  • Can be used interchangeably
  • Torque handle calibrated to ensure that the correct torque is given at the nut/ bolt
  • Nineteen versions with different ranges and ring sizes available
  • Also available in imperial sizes
  • Blank end adapters are available for applications requiring a customised spanner (please call for details)
  • Open-end and flare-end models are available
  • Useful additions to the Norbar 16mm Spigot-ended Torque Handles

What’s Included?

  • Your choice of Norbar Spanner End Fitting for 16mm Torque Handles – Ring End, Metric
NOR-29894 - Product Specifications Technical Specifications NOR-29885 - Product Specifications Technical Specifications NOR-29913 - Product Specifications Technical Specifications NOR-29915 - Product Specifications Technical Specifications NOR-29881 - Product Specifications Technical Specifications NOR-29888 - Product Specifications Technical Specifications NOR-29893 - Product Specifications Technical Specifications NOR-29884 - Product Specifications Technical Specifications NOR-29891 - Product Specifications Technical Specifications NOR-29896 - Product Specifications Technical Specifications NOR-29887 - Product Specifications Technical Specifications NOR-29892 - Product Specifications Technical Specifications NOR-29883 - Product Specifications Technical Specifications NOR-29890 - Product Specifications Technical Specifications NOR-29895 - Product Specifications Technical Specifications NOR-29886 - Product Specifications Technical Specifications NOR-29914 - Product Specifications Technical Specifications NOR-29882 - Product Specifications Technical Specifications NOR-29889 - Product Specifications Technical Specifications
