Megger TDR2000/3P Dual Channel Power Plus Time Domain Reflectometer - With Accessories

The Megger TDR2000/3 Dual Channel Power Plus Time Domain Reflectometer and Megger TDR2000/3P Dual Channel Power Plus Time Domain Reflectometer differ only in regards to their supplied test lead sets.

The Megger TDR2000/3 Dual Channel Power Plus Time Domain Reflectometer is supplied with two pairs of 2m test leads with 4mm shrouded connections to miniature crocodile clips.

The Megger TDR2000/3P Dual Channel Power Plus Time Domain Reflectometer is supplied with two pairs of 1.5m retractable sheath fused test leads.

The Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers can be used to locate faults on metallic paired cables. The velocity factor can be set to a value between 0.2 and 0.99 allowing the reflectometers to be programmed to accommodate a variety of cable test requirements.

Depending on the value of the velocity factor and the cable type, the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers have a maximum range of 20km/ 65 kft. The Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers can be programmed to display readings in either metres or feet and have a minimum resolution of 0.1m/ 0.3 ft.

The high-resolution and the large, WVGA displays' white backlights and user-selectable colour palettes increase the ease and clarity with which key events within the trace can be identified. The Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers feature two user-selectable colour palettes, default and outdoors, as well as a custom slot allowing the user to specify the colour of up to seven screen elements. The various colour schemes ensure that the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers can be tailored to suit the environment and/or application, as well as accommodate for eye conditions such as colour blindness.

In addition to this, the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers feature an IP54 rated, compact, durable design ensuring that they are suitable for use in rugged indoor and outdoor environments. They are also equipped with a rechargeable Li-ion battery capable of providing the cable fault locators with up to twelve hours of power, making these instruments suitable for prolonged testing on challenging work sites.

Accessing the required settings, features, functions and modes is simple due to the intuitive and easy-to-use interface consisting of directional control buttons and soft keys. The user can override the Auto Selection function to program the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers to his/her preferences specifying the gain and pulse as well as impedance output. The Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers are capable of issuing the following impedance outputs: 25Ω, 50Ω, 75Ω, 100Ω and 125Ω. Overriding the Auto Selection function to program the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers manually is particularly useful when trying to identify hard-to-determine faults.

Alternatively, the Auto Selection function (unless overridden as mentioned above) will configure the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers’ settings to ensure they are set to the most effective parameters for testing each cable. It will select the most relevant gain and pulse for each range as well as match the output impedance to the cable using an automatic impedance matching feature.

Further to this, the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers include a number of modes and features designed to improve the ease and efficiency of locating faults along cables.

AutoFind Mode

This mode automatically adjusts the gain and range ensuring that the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers' parameters are configured to identify the cable fault using the most efficient method.

When the button for the AutoFind Mode is pressed it will move the cursor to the first event on the cable; when pressed a second time it will move the cursor to the next detected disturbance.

Dual Trace and Dual Cursor

The dual trace and dual cursor capabilities provide the user with complete control over the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers whilst also ensuring that he/she receives an instant indication of the distance between two points. These features add to the adaptability and flexibility of the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers.

Trace Comparison

This feature facilitates a comprehensive examination of trace conditions allowing the user to identify key events quickly, accurately and reliably.

Up to one-hundred traces can be saved to the Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers’ internal memories. Saved traces can be viewed via the instruments' displays using the recall function thereby enabling further analysis and/or comparison with the active trace.

Additionally, it is possible to download data to a PC or laptop via a USB port using the included USB lead and Megger TraceXpert Software. As well as downloading and uploading data, the Megger TraceXpert Software can be used to create reports.

The Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers are accurate, adaptable and dependable cable fault locators. They are suitable for testing a range of metallic paired cables in a variety of outdoor and indoor environments.

Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers Key Features

  • Available in two models that are supplied with different test leads
  • The Megger TDR2000/3P Dual Channel Power Plus Time Domain Reflectometer is supplied with two pairs of 1.5m retractable sheath fused test leads
  • The Megger TDR2000/3 Dual Channel Power Plus Time Domain Reflectometer is supplied with two pairs of 2m test leads with 4mm shrouded connections to miniature crocodile clips
  • Locate faults on metallic paired cables
  • Set the velocity factor to a value between 0.2 and 0.99 to accommodate a variety of cable test requirements
  • Maximum range: 20 km/ 65 kft (depending on the velocity factor and cable type)
  • Minimum resolution: 0.1m/ 0.3 ft
  • High resolution, white backlight and user-selectable colour palettes increase the ease and clarity with which key events within the trace can be identified
  • Large, backlit, colour, WVGA display
  • Two user-selectable colour palettes: default and outdoors
  • Custom slot: specify the colour of up to seven screen elements
  • Selectable colour palettes and custom slot allow the user to tailor the instrument to the environment and/or application
  • Adjustable colour palettes and a custom slot accommodate for eye conditions such as colour blindness
  • IP54 rated, compact, durable design
  • Suitable for use in rugged environments
  • Equipped with a rechargeable battery capable of providing up to 12 hours of power
  • Intuitive, easy-to-use interface consisting of directional control buttons and soft keys
  • Auto Selection function optimised for locating faults quickly
  • Auto Selection function selects the most relevant gain and pulse for each range
  • Auto Selection function utilises the automatic impedance matching feature to match the output impedance to the cable
  • Auto Selection function can be overridden
  • Overriding the Auto Selection feature is useful when identifying hard-to-determine faults
  • AutoFind Mode automatically adjusts gain and range
  • AutoFind Mode ensures that cable faults can be identified using the most efficient method
  • AutoFind Mode places the cursor at the first event; when the mode button is pressed again the cursor is moved to the next detected disturbance
  • Dual trace and dual cursor provide the user with complete control
  • Dual trace and dual cursor ensure that the user receives an immediate indication of the distance between two points
  • Dual trace and dual cursor improve the flexibility and adaptability of the reflectometer
  • Trace comparison provides a comprehensive examination of trace conditions
  • Trace comparison facilitates the quick, accurate and reliable identification of key events
  • Save up to 100 traces to the reflectometers’ internal memories
  • Recall saved traces to the display for further analysis and/or comparison to the active trace
  • Download data to a PC or laptop via a USB port
  • Supplied with a USB lead
  • Supplied with a Megger TraceXpert Software for downloading and uploading data as well as creating reports
  • Accurate, adaptable and dependable cable fault locators
  • Suitable for testing a range of metallic paired cables in a variety of outdoor and indoor environments

What’s Included?

 Megger TDR2000/3 Dual Channel Power Plus Time Domain Reflectometer

  • Megger TDR2000/3 Dual Channel Power Plus Time Domain Reflectometer
  • 2x 2m Test Lead Sets with 4mm Shrouded Connection to Miniature Crocodile Clips
  • Megger TraceXpert Software
  • USB Lead
  • AC-DC Charger
  • User Guide CD

Megger TDR2000/3P Dual Channel Power Plus Time Domain Reflectometer

  • Megger TDR2000/3P Dual Channel Power Plus Time Domain Reflectometer
  • 2x 1.5m Retractable Sheath Fused Test Lead Sets
  • Megger TraceXpert Software
  • USB Lead
  • AC-DC Charger
  • User Guide CD
Products TDR2000/3 TDR2000/3P
Megger TDR2000/X Dual Channer Power Plus Time Domain Reflectometer X X
2x 2m Test Lead Sets with 4mm Shrouded Connection to Miniature Crocodile Clips X
2x 1.5m Retractable Sheath Fused Test Lead Sets X
Megger TraceXpert Software X X
USB Lead X X
AC-DC Charger X X
User Guide CD X X

Megger TDR2000/3/3P Dual Channel Power Plus Time Domain Reflectometers Technical Specifications

Specifications
Except where otherwise stated, this specification applies at an ambient temperature of 20°C
General Specifications
Range: Up to 20000 m with a minimum resolution of 0.1 m
m ft ns
10 30 125
25 80 250
50 160 500
100 320 100
250 800 2500
500 1600 5000
1000 3200 10000
2500 8000 25000
5000 16000 50000
10000 32500 100000
20000 65000 200000
Accuracy ±1% of range ±1 pixel at 0.67 VF [Note - The measurement accuracy is for the indicated cursor position only and is conditional on the velocity factor being correct.
Resolution 1% of range
Input protection This instrument complies with IEC61010-1 to protect the user in the event of connection to live systems. Rated at 150 V CAT IV, designed for use on de-energised systems and fused leads must be used if the potential voltage between terminals could exceed 300 V
Output pulse Up to 20 volts peak to peak into open circuit. Pulse widths determined by range, cable and model used.
Gain Set for each range with user selectable steps (in Manual operating mode).
Velocity factor Variable from 0.2 to 0.99 in steps of 0.01
TX null

Automatic

Trace Tagging - 32 characters chosen from upper case letters including accents

Colour schemes - Default, Outdoor, Custom

Cable Impedance: 25, 50, 75, 100, 125 ohm + AUTO.

Power down User programmable auto power off timer 1, 5, 10 mins or never
Battery Li-ion rechargeable battery
Battery charge time 6 hours at 0 °C to 40 °C
Battery life 12 hours typical
Safety These instruments comply with IEC61010-1 for connections to live systems up to 150 V CAT IV or 300 V CAT III. Compliant with EN60950-1, EN61010-1, UN38.3 and EN62133
EMC Complies with Electromagnetic Compatibility Specifications (Light industrial) BS EN 61326-1, with a minimum performance of ‘B’ for all immunity tests.
Mechanical Specifications
IP rating The instrument is designed for use indoors or outdoors and is rated to IP54.
Case ABS
Dimensions 290 mm (11.4 in) x 190 mm (7.5 inches) x 55 mm (2.2 inches)
Weight 1.7kg (3.8lbs)
Connectors Four 4mm-safety terminals and two F connectors. Other standard push on adapters will fit.
Test lead 2 pairs 2 meters long consisting of 2 x 4 mm shrouded connector to miniature crocodile clips
Display 800 x 480 pixel colour graphics LCD, viewable in external environments.
Colour Schemes: 8x selectable; 2x custom
Backlight Permanent backlight with all colour schemes (adjustable brightness)
Environmental Specifications
Operating temperature range and humidity -15 °C to +50 °C (5 °F to 122 °F)
Storage temperature range and humidity -20 °C to 70 °C (-4 °F to 158 °F)
