Mark-10 MESUR™ Gauge Plus Software - Choice of Licences

*** Please note that the Mark-10 MESUR™ Gauge Software is available as a single licence or as five licences. ***

The Mark-10 MESUR™ Gauge Plus Software is an easy-to-use, effective and eclectic analysis, documenting ad programming tool. Like its sister product, the Mark-10 MESUR™ Gauge Software, it can be used with a Mark-10’s force and torque measuring gauges and indicators, as well as select Mark-10 test stands. However, this version (the Mark-10 MESUR™ Gauge Plus Software) varies in that it is also able to control the motion of compatible Mark-10 ESM303, ESM303H, ESM750, ESM750S, ESM1500 and ESM1500S Motorised Test Stands, allowing the user to coordinate motion control and data collection with a single click.

The user is able to save customised test setups to the Mark-10 MESUR™ Gauge Plus Software which may be recalled when required. The user can program test parameters such as start and stop conditions including load, time, distance and sample break. It is also possible to configure select Mark-10 gauges remotely from a PC.

The Mark-10 MESUR™ Gauge Plus Software simulates a large version of the force/ torque instrument’s display allowing the user to monitor load and travel data in real-time. Data is displayed in a tabular or graphical format and the user can view load vs time or load vs travel vs time. Further to this, the Mark-10 MESUR™ Gauge Plus Software will automatically perform recalculations for custom data ranges and includes other useful data analysis functions such as statistical calculations and pass/ fail indicators.

Acquired data can be used to generate customised reports. Alternatively, data can be exported from the Mark-10 MESUR™ Gauge Plus Software to MS Excel at the touch of a button.

The Mark-10 MESUR™ Gauge Plus Software is a comprehensive, customisable load and travel analysis software program that can be used to expand the functionality of Mark-10 force and torque gauges, indicators and test stands.

Mark-10 MESUR™ Gauge Plus Software Key Features

• Easy-to-use, effective and eclectic analysis, documenting and programming tool
• Use with Mark-10’s force and torque measuring gauges, indicators and test stands
• Can control the motion of Mark-10 ESM303, ESM303H, ESM750, ESM750S, ESM1500 and ESM1500S Motorised Test Stands
• Single click coordination of test stand motion control and data collection
• Customise, save and recall test setups
• Program test parameters such as start and stop conditions including load, time, distance and sample break
• Configure select Mark-10 gauges remotely from a PC
• Simulates a large version of the force/ torque instrument’s display
• Monitor load and travel data in real-time
• Data is displayed in a tabular or graphical format
• View load vs time or load vs travel vs time
• Automatically performs recalculations for custom data ranges
• Statistical calculations
• Pass/ fail indicators
• Generate reports
• Customisable report templates
• Export data to MS Excel at the touch of a button
• Integrated simulated data generation allows the software to be evaluated without an instrument
• Comprehensive, customisable load and travel analysis software program
• Expands the functionality of Mark-10 force and torque gauges, indicators and test stands

What’s Included?

• Mark-10 MESUR™ Gauge Plus Software – Single Licence OR Five Licences

To view a comparison chart between the standard, Plus and Lite versions of the Mark-10 MESUR™ Gauge Software, please see the 'Technical Specifications'.
