FLIR Si2-PD Industrial Acoustic Imager – Partial Discharge
FLIR Si2-PD Industrial Acoustic Imager – Partial Discharge
The FLIR Si2-PD Industrial Acoustic Imager is a sensitive, simple-to-use, safety-optimised sonic imager designed for pinpointing partial discharge (PD). A perfect condition monitoring tool for the electric, power, and utilities industries, the FLIR Si2-PD Industrial Acoustic Imager is designed to make maintenance managers’, substation managers’, reliability specialists’, and thermographers’ jobs easier and quicker.
New Features
Building on the success of its predecessor, the FLIR Si124-PD Industrial Acoustic Imager, the FLIR Si2-PD Industrial Acoustic Imager can detect partial discharge faults thirty times smaller than previously possible and from a safe distance of 200m away from the issue. In addition to this, it includes the following new features:
- 12MP digital camera
- 8x digital zoom
- 1280 x 720px, 5-inch colour screen
- Identify, classify, and assess the severity of PD
- Built-in LED lights
- Fleet Management functionality
Advanced Partial Discharge Detection
124 microphones strategically arranged for high performance combined with a 12MP digital camera, and 8x digital zoom, ensures the FLIR Si2-PD Industrial Acoustic Imager can locate and classify PD faults, as well as assess the severity of these defects from up to 200m (656 ft). Such a long detection range not only enables the identification of tricky-to-access issues but also ensures staff are kept safe when surveying dangerous equipment.
One-handed operation and automatic tuning add to the ease and efficiency of the FLIR Si2-PD Industrial Acoustic Imager, maximising inspection productivity.
Comprehensive Analysis Tools
The FLIR Si2-PD Industrial Acoustic Imager offers best-in-class decision support due to on-camera and software-based severity assessment of partial discharge issues and PD classification. It also provides recommended actions aiding in swift decision-making and suitable response/repair planning. Again, this improves the simplicity and speed of maintenance inspections.
Fleet Management Functionality
Support for Cloud data integration and OTA software means the FLIR Si2-PD Industrial Acoustic Imager can accommodate enterprise scaling allowing managers to ensure tools are being used and maintained correctly.
Applications
As a result of its sophisticated yet simple-to-use design and PD optimisation, the FLIR Si2-PD Industrial Acoustic Imager is perfect for:
- Monitoring transmission and distribution conductors/components reducing the need for repairs
- Inspecting substation transformers to identify PD issues before they develop further potentially resulting in dangerous and costly explosions
- Finding PD in high voltage equipment which can have the advantage of reducing public complaints about radio interference and noise
A powerful and practical ultrasonic imager, the FLIR Si2-PD Industrial Acoustic Imager empowers you to make precise maintenance decisions, save money, protect the public, and prevent downtime.
Videos
FLIR Si2 Acoustic Camera 2024: What You Need to Know
Key Features
- A sensitive, simple-to-use, safety-optimised sonic imager designed for pinpointing partial discharge
- Condition monitoring tool for the electric, power, and utilities industries
- Perfect for maintenance managers, substation managers, reliability specialists, and thermographers
- NEW: Detect partial discharge from up 200m away from the source
- NEW: Detect partial discharge faults thirty times smaller than previously possible
- NEW: Identify, classify, and assess the severity of PD
- NEW 12MP digital camera
- NEW 8x digital zoom
- NEW 1280 x 720px, 5-inch colour screen
- NEW Built-in LED lights
- NEW Fleet Management functionality
- 124 microphones strategically arranged for maximum performance
- Identify tricky-to-access issues while maintaining staff safety
- One-handed operation
- Automatic tuning
- Best-in-class decision support
- On-camera and software-based severity assessment of partial discharge issues and classification
- Provides recommended actions
- Support for Cloud data integration and OTA software
- Monitor transmission and distribution conductors/components
- Inspect substation transformers to identify PD issues before they develop into dangerous and costly explosions
- Find PD in high-voltage equipment
- Powerful and practical ultrasonic imager
- Empowers you to make precise maintenance decisions, save money, protect the public, and prevent downtime
What’s Included?
- FLIR Si2-PD Industrial Acoustic Imager – Leak Detection
- Battery
- Battery Charger
- Power Cable
- Neck Strap
- Licence Card: FLIR Si-Series Plugin for FLIR Thermal Studio, Perpetual Licence
- USB Stick
- Printed Documentation
- Hard Transport Case
FLIR Si-Series Acoustic Imaging Camera Comparison Chart
| Si124-LD PLUS | Si2-LD | Si2-PD | Si2-Pro | |
| Leak Detection (LD) | ✓ | ✓ | × | ✓ |
| Mechanical Fault Detection (MD) | × | ✓ | × | ✓ |
| Partial Discharge mode (PD) | × | × | ✓ | ✓ |
| PD Severity Assessment on camera | × | × | ✓ | ✓ |
| Quick start with a press of the power button | ✓ | ✓ | ✓ | ✓ |
| Minimum Detectable Leak Rate (MDLR) | 0.011 l/min @ 3 m | 0.0032 l/min @ 2.5 meters | N/A | 0.0032 l/min @ 2.5 meters |
| AutoFilter | ✓ | ✓ | ✓ | |
| AutoDistance | ✓ | ✓ | × | ✓ |
| Continuous Auto-Correct | ✓ | ✓ (improved) | ✓ (improved) | ✓ (improved) |
| ATEX Certified | × | × | × | × |
| Compatible with Thermal Studio | ✓ | ✓ | ✓ | ✓ |
| Compatible with Acoustic Viewer | ✓ | ✓ | ✓ | ✓ |
| Frequency Range 2-130kHz | × | ✓ | ✓ | ✓ |
| Frequency Range 2-65kHz | ✓ | × | × | × |
| Video Recording (up to 5 min) | ✓ | ✓ | ✓ | ✓ |
| IP Rating | IP51 | IP54 | IP54 | IP54 |
| Battery Life | Up to 2,5h (depends on ambient conditions) | Up to 2,5h (depends on ambient conditions) | ||
| Detection Range | 100m in optimal conditions (optimal work range is 1-15m) | Depending on the environment and application, the range can be up to 200 meters. | ||
FREE FLIR Studio Pro Software
- FLIR Thermal Studio Pro Software – 12-Month Licence - T300243, typically £419.00
FLIR Si2-PD Industrial Acoustic Imager – Partial Discharge Technical Specifications
| Acoustic Measurement | |
| Detection threshold | 20 kHz: -7 dB SPL 35 kHz: 4 dB SPL 50 kHz: 10 dB SPL 80 kHz: 36 dB SPL 100 kHz: 51 dB SPL |
| Bandwidth | 2 kHz to 130 kHz |
| Directional resolution | From 1° up to 0.125° |
| Operating distance | From 0.3 m (1.0 ft) up to 200 m (656 ft) |
| Severity Assessment | Automatic AI-based severity assessment including recommended actions onboard camera |
| Imaging & Optical | |
| Digital camera | 12 MP colour |
| Camera field of view | 75° diagonal |
| Video frame rate | Camera: 60 fps / Acoustic image: 30 fps / Screen: 70 fps |
| Zoom | 8x Digital zoom |
| Video image resolution | 1280 × 720 |
| User Interface | |
| Display | Size: 5 in. 1280 × 720 Resistive touch screen, TFT LCD, MIPI DSI |
| Integrated flashlight | LEDs, three modes off, normal and bright |
| Analysis and Reporting | |
| Online | FLIR Acoustic Camera Viewer (cloud service) www.acousticviewer.flir.com |
| Offline | FLIR Thermal Studio (desktop software) |
| Communication & Data Storage | |
| Data transfer | Wi-Fi 2.4 GHz and 5 GHz IEEE 802.11.b/g/n/ac wireless LAN USB memory stick |
| Camera software update | Automatic Over The Air (OTA) wireless update or via USB connection |
| Still image format | .nlz and .jpg |
| Video recording & format | Up to 5 minutes (.nlz format) |
| Storage, internal | 128 GB (SD card) |
| Storage, external | USB 8 GB, Cloud storage capacity is unlimited |
| Image annotations | Image tags and comments |
| Power Supply | |
| Camera power input | Nominal input voltage: 12 V DC Max input: 17 V DC , 3.3 A (limited) |
| Battery | Li-Ion rechargeable battery pack (RRC 2054):14.4 V DC, 3.45 Ah, 49.68 Wh Usage: Up to 2.5 h (depends on ambient conditions & usage, needs to be retested and confirmed with final product) Charge time: approx. 2 h Max output: 16.8 V DC, 5 A |
| Battery charger | Input: 19-26 V DC, 2.8 A Max output: 17.4 V DC, 4.8 A |
| Environmental Data | |
| Operating temperature range | -10°C to 50°C (14°F to 122°F) |
| Storage temperature range | -20°C to 50°C max -20°C to 25°C recommended (determined by the battery) |
| Relative humidity | 0-90% recommended |
| EMC | CFR47 FCC Part 15 Subpart B |
| Radio | CFR47 FCC Part 15 Subpart C/E, ETSI EN 301 489-1/-17/-19, ETSI EN 300 328, ETSI EN 301 893 |
| Protection class | IP54 |
| Safety | IEC 62368-1 |
| Declaration of conformity | See: https://support.flir.com/resources/DoC |
| Physical Data | |
| Camera size | 288 mm × 182 mm × 159 mm (11 in × 7 in × 6 in) |
| Camera weight | ~ 1.2 kg |
| Battery size | 85 mm × 77 mm (RRC2504) |
| Battery weight | ~ 0.25 kg |
| Total weight (camera + battery) | ~ 1.45 kg |
Reviews
Additional Information
| SKU | T912305 |
|---|---|
| Manufacturer Part Code | T912305 |
