Chauvin Arnoux CA6526 Insulation & Continuity Tester
Chauvin Arnoux's CA6526 insulation tester includes everything you need for testing insulation and other electrical parameters over a wide range and also has the added benefit of built-in downloadable memory storage.
With the CA6526 as part of your equipment, you'll be able to test insulation resistance, current leakage, PI/DAR ratios, continuity, voltage, frequency, resistance and capacitance. You can log all of your measurement results directly into the tester's memory, then download them to your PC ready for further analysis using Chauvin Arnoux's included software package.
New Chauvin Arnoux Insulation Testers (EN)
The Chauvin Arnoux CA6526 can test insulation resistance levels of up to 200GΩ with selectable test voltages of 50, 100, 250, 500 and 1000V. Users can also program the duration of the test and use PI/DAR ratio modes to determine the quality of the insulation without results being influenced by temperature.
For added convenience, the CA6526 includes a built-in magnetic mounting system, allowing it to be easily attached to an electrical panel or metallic surface for hands-free use.
This insulation tester is CAT IV 600V safety rated.
Chauvin Arnoux CA6526 Insulation Tester Key Features
- Test insulation resistance to 200GΩ with selectable test voltages of 50, 100, 250, 500 and 1000V
- Current leakage function
- Manual, lock and duration testing modes
- PI/DAR ratio modes
- User-programmable alarm limits
- Continuity tests
- Voltage tests
- Frequency tests
- Resistance tests
- Capacitance tests
- Magnetic mount on the back
- Internal memory storage with download to PC
What's Included?
- Chauvin Arnoux CA6526 Insulation Tester
- Carrying Bag
- 2 x Test Leads
- Croc Clip
- Test Probe
- 6 x Batteries
- Quick Startup Guide
- Safety Datasheet
- Transfer Software
Optional Accessories/Replacement Parts
If you would like to order any of these additional accessories or replacement parts, please call our sales team quoting the part number shown.
| Optional Accessories | |
|---|---|
| Part Number | Description |
| P01102092A | Remote Control Probe |
| P01102084A | Continuity Rod |
| P01650101Z | Thermometer + Type K Thermocouple |
| P01156301Z | Thermo Hygrometer |
| P01102112 | USB-Bluetooth Adapter (not compatible with CA6522) |
| P01102095 | DataView Software (not compatible with CA6522) |
| Replacement Parts | |
| Part Number | Description |
| P01295453Z | 2 x Elbowed Straight Safety Leads (Red and Black), 1.5m Length |
| P01295457Z | 2 x Croc Clips (Red and Black) |
| P01295454Z | 2 x Test Probes (Red and Black) |
| P01102053Z | 2 x Wire Grips (Red and Black) |
| P01298049 | Carrying Bag for Hands-Free Use |
Chauvin Arnoux CA6500 Series Tech Specs/Comparison Chart
| Model Number | CA6522 | CA6524 | CA6526 | CA6532 | CA6534 | CA6536 |
|---|---|---|---|---|---|---|
| Voltage | ||||||
| Measurement Range (Resolution) | 0.3V to 399.9V (0.1V) 400V to 700V (1V) |
|||||
| Accuracy (Input Impedance) | ±(3% + 2 cts) (400kΩ) | |||||
| Operating Frequency | DC: 15.3 to 800Hz | |||||
| Frequency | ||||||
| Measurement Range | N/A | 15.3Hz to 399.9Hz: 0.1Hz Resolution, ±(1% + 2cts) accuracy 400 to 800Hz: 1Hz resolution, ±(1% + 1 ct) accuracy |
N/A | N/A | ||
| Insulation | ||||||
| Test Voltage | 250, 500 and 1000V | 50, 100, 250, 500 and 1000V | 50 and 100V | 10, 25, 100, 250 and 500V | 10V to 100V in 1V steps | |
| Range at Maximum Test Voltage | 40GΩ | 200GΩ | 20GΩ | 50GΩ | 20GΩ | |
| Compliance with IEC 61557-2 Standard | 2GΩ | |||||
| Measurement Range: 10V | N/A | N/A | N/A | N/A | 2kΩ to 1GΩ | 2kΩ to 2GΩ |
| Measurement Range: 25V | N/A | N/A | N/A | N/A | 5kΩ to 2GΩ | 2kΩ to 2GΩ |
| Measurement Range: 100V | N/A | 10kΩ to 10GΩ | 10kΩ to 10GΩ | 10kΩ to 10GΩ | N/A | (UN/5) kΩ - (UN/5) GΩ |
| Measurement Range: 250V | 50kΩ to 10GΩ | 50kΩ to 50GΩ | 50kΩ to 50GΩ | N/A | 50kΩ to 25GΩ | N/A |
| Measurement Range: 500V | 100kΩ to 20GΩ | 100kΩ to 100GΩ | 100kΩ to 100GΩ | N/A | 100kΩ to 50GΩ | N/A |
| Measurement Range: 1000V | 200kΩ to 40GΩ | 200kΩ to 200GΩ | 200kΩ to 200GΩ | N/A | N/A | N/A |
| Variable Test Voltage | N/A | N/A | N/A | N/A | N/A | 10V to 100V |
| Measurement Range/Resolution | 10(1) - 999 kΩ and 1.000 - 3.999 MΩ / 1 kΩ; 4.00 - 39.99 MΩ / 10 kΩ; 40.0 - 399.9 MΩ / 100 kΩ; 400 - 3,999 MΩ / 1 MΩ; 4.00 - 39.99 GΩ / 10 MΩ; 40.0 - 200 GΩ / 100 MΩ |
|||||
| Accuracy | ± (3 % + 2 cts)(2) | ± (3 % + 2 cts)(3) | ||||
| Test Voltage (I < 1mA) | - 0 % + 20 % | ±0.5V | ||||
| Display of Test Voltage | ±(3% + 3 cts) | ±(3% + 3cts) | ||||
| Display of Test Current/Resolution | N/A | 0.01 μA - 39.99 μA / 10 nA; 40.0 - 399.9 μA / 100 nA; 0.400 - 2.000 mA/ 1 μA | ||||
| Accuracy of Test Current | N/A | ±(10% + 3 cts) | ||||
| PI/DAR Ratios | N/A | 10 min/ 1 min to 1 min / 30s | N/A | N/A | ||
| Timer (min:s) | 0:00 to 39:59 | |||||
| Discharge Time (at 25V) | <2s/μF | |||||
| Alarms | N/A | 2 fixed thresholds + 1 programmable threshold | ||||
| Continuity | ||||||
| Range for Continuity Measurement | 0.00Ω to 10.00Ω (200mA) | 0.00 to 10.00Ω (200mA) 0.0 to 100.0Ω (20mA) |
||||
| Accuracy/Open Circuit Voltage | ±(2%+2cts) / ≥6V | |||||
| Measurement Current | 200mA range: 200mA (-0ma +20mA) 20mA range: 20mA ±5mA |
|||||
| Continuity Thresholds (Quick Beep) | 2Ω fixed | 2Ω, 1Ω, programmable | ||||
| Compensation of Cables | Up to 9.99Ω | |||||
| Resistance | ||||||
| Measurement Range/ Resolution / Accuracy | 0 - 3,999 Ω / 1 Ω; 4.00 kΩ - 39.99 kΩ / 10 Ω / ± (3 % + 2 cts) 40.0 kΩ - 399.9 kΩ / 100 Ω; 400 kΩ - 1,000 kΩ / 1 kΩ / ± (3 % + 2 cts) |
|||||
| Capacitance | ||||||
| Measurement Range / Resolution | N/A | N/A | 0.1 nF - 399.9 nF / 0.1 nF 400 nF - 3,999 nF / 1 nF 4.00 μF - 10.0 μF / 10 nF |
N/A | N/A | |
| Accuracy | N/A | N/A | ±(3% + 2cts) | N/A | N/A | |
| Line Length | N/A | N/A | N/A | 0 to 100km | N/A | N/A |
| General Specifications | ||||||
| Display | 2 x 4000 cts + logarithmic bargraph | |||||
| Storage | N/A | 300 measurements | 1300 measurements | N/A | ||
| Communication | N/A | N/A | Bluetooth Class II | N/A | ||
| Power Supply/ Automatic Shutdown | 6 x LR6(AA) batteries / 5 min, deactivatable | |||||
| Battery Life | 1,500/2,500/6,000 measurements (4): UN x 1 kΩ @ UN (5 s ON / 55 s OFF); 3,000 continuity measurements (5 s ON / 55 s OFF) | |||||
| Dimensions (H x W x D) | 211 x 108 x 60mm | |||||
| Weight | 850g | |||||
| IP Rating | IP54 | |||||
| EMC/Electrical Safety | IEC 61326 - 1 / IEC 61010 - 1 and IEC 61010 - 2 - 030, 600 V CAT IV | |||||
| Compliance with Standards | IEC 61557 parts 1, 2, 4 and 10 | |||||
(1): 2 kΩ for C.A 6532 - C.A 6534 - C.A 6536 – (2): to be added: 10 V: 1 % per 0.1 GΩ ; 25 V: 0.4 % par 0.1 GΩ , 50 V: 2 % per GΩ, 100 V: 1 % per GΩ ; 250 V: 0.4 % per GΩ; 500 V: 0.2 % per GΩ; 1,000 V: 0.1 % per GΩ
(3): 10 % /UN is added per 100 MΩ – (4): depending on model.
